Glazing submittals are the bridge between the architect’s design and the glass that shows up on site. They include shop drawings, product data, samples, and engineering calculations. When they move quickly and cleanly, the job stays on schedule. When they stall, the whole facade can fall weeks behind. This guide explains what general contractors should expect in a glazing submittal package and how to keep reviews moving.
We will cover each part of the package, the review cycle, common reasons for rejection, and simple ways to avoid resubmittals.
Why Glazing Submittals Matter
Glass systems are custom-built for each project. The shop cannot cut aluminum or order glass until the team locks in the design. Therefore, approved submittals are the green light for fabrication.
In addition, submittals protect everyone. First, they show the architect exactly what the glazier plans to build. Second, they give the owner a record of the approved products. Also, they help the GC coordinate with other trades before any work goes in.
Because glass carries long lead times, every week of submittal delay can push delivery back a week or more. So for general contractors, managing glazing submittals is a schedule priority.
What Goes Into a Glazing Submittal Package
A complete package usually includes several parts:
- Shop drawings with elevations, sections, and details
- Product data for frames, glass, sealants, gaskets, and hardware
- Samples of frame finishes and glass makeups
- Structural calculations for wind load, glass, and anchors
- Thermal data such as U-factor and solar heat gain numbers
- Test reports for air, water, and structural performance
- Warranty information from makers and the installer
Some specs also require mockup drawings, installer qualifications, or sealant compatibility tests. Read the submittal section of each spec to build a full list.
Shop Drawings in Detail
Shop drawings are the heart of the package. They translate the design into exact, buildable details. Typically, they show:
- Every elevation with unit sizes and mullion layout
- Plan and section details at heads, sills, and jambs
- Anchor types, sizes, and spacing
- Glass types tagged by location
- Flashing, sealant joints, and air barrier tie-ins
- Door locations, swings, and hardware prep
Good shop drawings also call out field dimensions that still need verification. That way, everyone knows which numbers the crew will check on site.
Product Data and Specifications
Product data sheets prove that each material meets the spec. For example, the glass data should show the coating, thickness, and performance values. The frame data should show the system, depth, and finish. Meanwhile, sealant data should confirm compatibility with adjacent materials.
Highlight the exact products and options on each sheet. Reviewers should not have to guess which version you plan to use. Many specs reference standards from groups like the Fenestration and Glazing Industry Alliance, so include test data that matches those standards.
Samples and Finish Selection
Samples let the design team see and touch the real materials. Most packages include small frame pieces in the chosen finish. They also include glass samples that show the coating and tint.
Color can look different in the office and on the building. So many architects ask to view glass samples outside, in daylight. Some also ask for a larger sample or a mockup panel. Plan for this step. If the team rejects a finish, the glass order may wait.
Keep the approved samples on site. Then, when the glass arrives, the crew can compare it with the sample. Any big mismatch is easy to spot before the glass goes in.
Calculations and Engineering
When the spec calls for delegated design, the glazier’s engineer must prove the system works. Calculations usually cover wind loads on glass and frames, anchor capacity, and deflection limits. In some areas, they must carry a licensed engineer’s stamp.
For the GC, the main task is coordination. Make sure the structural engineer of record reviews anchor loads on the building. Also, confirm that embed plates or blocking appear on the right drawings.
How the Review Cycle Works
Glazing submittals usually follow this path:
- The glazier prepares the package.
- The GC reviews it for completeness and coordination.
- Next, it goes to the architect.
- The architect and consultants review it.
- Then it comes back with a status and comments.
- If needed, the glazier revises and resubmits.
Reviewers often use statuses like “approved,” “approved as noted,” and “revise and resubmit.” An “approved as noted” status often allows fabrication to start while minor comments get addressed.
Why Glazing Submittals Get Rejected
Most rejections trace back to a few causes. Knowing them helps you avoid them.
- Missing items: Calculations, samples, or test reports were left out.
- Spec deviations: A product differs from the spec without explanation.
- Unclear details: Key joints or tie-ins are not shown.
- Coordination gaps: The drawings conflict with structure or cladding.
- Poor organization: Reviewers cannot find what they need.
Tips to Speed Up Approvals
You cannot control how fast the architect reviews. However, you can control the quality of what you send. Here are proven tips:
- Hold a submittal kickoff meeting with the glazier and architect.
- Agree on the package order and format up front.
- Submit long-lead items, like glass and finishes, first.
- Do a GC review before forwarding the package.
- Flag any substitutions clearly with a reason.
- Answer comments within days, not weeks.
- Track every submittal in a shared log.
Some teams also split the package. For example, they send glass and finish samples early, then follow with full shop drawings. That way, the glass order can start sooner.
Glazing Submittals for Substitutions and Equals
Sometimes the glazier proposes a different product than the spec names. This can save cost or time. Still, substitutions need care. The glazier must show that the new product meets or beats the spec on performance, warranty, and look.
Submit substitution requests early, ideally before bidding closes. Late requests often face more scrutiny and may slow the whole package.
Using Approved Glazing Submittals in the Field
Approved drawings are more than paperwork. In fact, the field crew should build directly from them. Keep a current set on site, and make sure everyone uses the latest revision.
When field conditions differ from the drawings, document the change. Then update the drawings and notify the architect. This record becomes part of the as-built set at closeout.
Roles in the Review
Each person in the chain has a clear job. The glazier makes the package complete and accurate. Meanwhile, the GC checks it against the site and other trades. The architect checks it against the design intent. Consultants, such as the facade or structural engineer, check their own parts.
When each person knows their role, reviews move faster. Also, comments become clearer, because each reviewer focuses on what they know best.
Glazing Submittals and Closeout
At the end of the job, approved submittals feed directly into the closeout package. Owners need them to order replacement glass, service hardware, and plan future renovations. Therefore, keep the final approved versions organized and easy to find.
FAQ on Glazing Submittals
How long do glazing submittals take to approve?
It depends on the project and the review team. Simple storefront packages move faster than large curtain wall packages with calculations and testing.
Can fabrication start before full approval?
Sometimes, if the status allows it. Many teams release glass orders once the glass makeup is approved, even if minor drawing comments remain.
